Installation manual

Simplicity 64 & Simplicity 126 INSTALLATION MANUAL.
Approved Document No: GLT.MAN-107
Issue : 1.04 Authorised: GH Date: 05/10/2004
PAGE 17
ADDRESS SWITCHES ADDRESS SWITCHES ADDRESS SWITCHES ADDRESS SWITCHES
12345 6 7 1234567 1 2 34567 1234567
0 = n o t u s e d 32 = on on on on on off on 64 = on on on on on on off 96 = on on on on on off off
1 = off on on on on on on 33 = off on on on on off on 65 = off on on on on on off 97 = off on on on on off off
2 = on off on on on on on 34 = on off on on on off on 66 = on off on on on on off 98 = on off on on on off off
3 = off off on on on on on 35 = off off on on on off on 67 = off off on on on on off 99 = off off on on on off off
4 = on on off on on on on 36 = on on off on on off on 68 = on on off on on on off 100 = on on off on on off off
5 = off on off on on on on 37 = off on off on on off on 69 = off on off on on on off 101 = off on off on on off off
6 = on off off on on on on 38 = on off off on on off on 70 = on off off on on on off 102 = on off off on on off off
7 = off off off on on on on 39 = off off off on on off on 71 = off off off on on on off 103 = off off off on on off off
8 = on on on off on on on 40 = on on on off on off on 72 = on on on off on on off 104 = on on on off on off off
9 = off on on off on on on 41 = off on on off on off on 73 = off on on off on on off 105 = off on on off on off off
10 = on off on off on on on 42 = on off on off on off on 74 = on off on off on on off 106 = on off on off on off off
11 = off off on off on on on 43 = off off on off on off on 75 = off off on off on on off 107 = off off on off on off off
12 = on on off off on on on 44 = on on off off on off on 76 = on on off off on on off 108 = on on off off on off off
13 = off on off off on on on 45 = off on off off on off on 77 = off on off off on on off 109 = off on off off on off off
14 = on off off off on on on 46 = on off off off on off on 78 = on off off off on on off 110 = on off off off on off off
15 = off off off off on on on 47 = off off off off on off on 79 = off off off off on on off 111 = off off off off on off off
16 = on on on on off on on 48 = on on on on off off on 80 = on on on on off on off 112 = on on on on off off off
17 = off on on on off on on 49 = off on on on off off on 81 = off on on on off on off 113 = off on on on off off off
18 = on off on on off on on 50 = on off on on off off on 82 = on off on on off on off 114 = on off on on off off off
19 = off off on on off on on 51 = off off on on off off on 83 = off off on on off on off 115 = off off on on off off off
20 = on on off on off on on 52 = on on off on off off on 84 = on on off on off on off 116 = on on off on off off off
21 = off on off on off on on 53 = off on off on off off on 85 = off on off on off on off 117 = off on off on off off off
22 = on off off on off on on 54 = on off off on off off on 86 = on off off on off on off 118 = on off off on off off off
23 = off off off on off on on 55 = off off off on off off on 87 = off off off on off on off 119 = off off off on off off off
24 = on on on off off on on 56 = on on on off off off on 88 = on on on off off on off 120 = on on on off off off off
25 = off on on off off on on 57 = off on on off off off on 89 = off on on off off on off 121 = off on on off off off off
26 = on off on off off on on 58 = on off on off off off on 90 = on off on off off on off 122 = on off on off off off off
27 = off off on off off on on 59 = off off on off off off on 91 = off off on off off on off 123 = off off on off off off off
28 = on on off off off on on 60 = on on off off off off on 92 = on on off off off on off 124 = on on off off off off off
29 = off on off off off on on 61 = off on off off off off on 93 = off on off off off on off 125 = off on off off off off off
30 = on off off off off on on 62 = on off off off off off on 94 = on off off off off on off 126 = on off off off off off off
31 = off off off off off on on 63 = off off off off off off on 95 = off off off off off on off 127 = n o t u s e d
