8.1 LOOP CONTENTS FAULT FINDING
If the loop contents are different to what was expected, then there may be some wrong
connections to devices (they are polarity sensitive), or double addresses on the loop. (A
double address is when 2 or more devices have been set to the same address, so they
both answer at the same time.)
Return to the configuration menu & select option 5
(Dev status). Wait for the panel to read loop 1
address 001.
The panel will give the device type & its analogue value. If the device is configured, there
will be an asterix (*) next to the device type. Number of devices should read 1 (a reading of
2 or more will mean a double address is present).
Press next to move to the next address on the loop. (The Previous button cannot be used
in this menu. It can only be used to scroll between multiple faults or alarms.) Read all
devices on the loop and compare with what was expected. If one address has 2 devices,
and another is “missing”, the missing device could have a wrong address setting. If many
devices are missing, check that they have power. There may be more than one break in
the cable (the panel reads all devices when it has a single break, and will report a loop
fault after a minute or so).
8.2 ADDRESS - ZONE TABLE
On the SIMPLICITY, each available address corresponds to a zone, with 1-16 being in
zone 1, 17-32 being in zone 2, 33-48 in zone 3 etc.
The table below shows the dip switch settings for each address, and the zone that address
will be in.
Eg to set address 37, find 37 in the table. It is at sw 7,6,5 = 010, and sw 4,3,2,1= 0101
Remembering that 0 = ON & 1 = OFF, the switch settings for 37 are:
7=ON, 6=OFF, 5=ON, then 4=ON, 3=OFF, 2=ON, 1=OFF
(NOTE: Only 4 zones are available on the Simplicity 64)
As an alternative to using this chart, use the table on the following page:-
SW 4,3,2,1
OOOO OOO1 OO1O OO11 O1OO O1O1 O11O O111 1OOO 1OO1 1O1O 1O11 11OO 11O1 111O 1111 LOOP 1 LOOP 2
SW OOO N/A 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 ZONE 1 ZONE 9
7,6,5 OO1 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 ZONE 2 ZONE 10
O1O 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 ZONE 3 ZONE 11
O11 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63 ZONE 4 ZONE 12
1OO 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79 ZONE 5 ZONE 13
1O1 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 ZONE 6 ZONE 14
11O 96 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 ZONE 7 ZONE 15
111 112 113 114 115 116 117 118 119 120 121 122 123 124 125 126 N/A ZONE 8 ZONE 16
Device Type: HEAT *
Value:26 No Devs:1
====================
Loop:1 Address:001
