Simplicity 64 & Simplicity 126 INSTALLATION MANUAL.
Approved Document No: GLT.MAN-107
Issue : 1.04 Authorised: GH Date: 05/10/2004
PAGE 13
SEALED LEAD ACID BATTERY
12V / 7 Ah
SEALED LEAD ACID BATTERY
12V / 7Ah
LIVE NEUT- EARTH
RAL
MAINS FUSE 3A HBC CERAMIC
CONN29
FS1
FS2
FS3
1
2
3
4
5
6
7
8
9
10
LOOP WIRING FLT REP
CLASS
CHANGE
A- A+ B- B+
+ + + +
+
11
12
13
THERMISTOR
Figure 4a:Thermistor location
The thermistor is used to prevent overcharging the batteries in high ambient temperatures.
7. FIELD DEVICE TERMINATION
7.1 TERMINATING THE ADDRESSABLE LOOP.
LIVE NEUT- EARTH
RAL
INLET MAINS
SUPPLY
INTERNAL
WIRING
Brass Glands
LIVE NEUT- EARTH
RAL
CONN29
FS1
FS2
FS3
1
2
3
4
5
6
7
8
9
10
LOOP WIRING FLT REP
CLASS
CHANGE
A- A+ B- B+
+ + + +
+
11
12
13
M
A
INS FUSE
2
A
HBC CER
A
MIC
CONN5
Figure 6: Addressable Loop Connection
7.2 AUXILIARY INPUT AND OUTPUT TERMINATIONS
Connect auxiliary input and output cables to the appropriate connector block terminals on the Termination
PCB (See Page 15). Screened cables should be terminated as per figure 6.
For a full description of the inputs and outputs available on the SIMPLICITY range of Fire Panels, including
typical wiring diagrams please refer to pages 5 & 6.
MAKE SURE ANY SPARE
ENTRY HOLES ARE
COVERED WITH THE
GROMMETS PROVIDED
