RIVERSIDE / LAWSON / CAYLEY ENTRYWAY BENCH MODEL # 3AXCRIV-04 1/13
FOR REPLACEMENT PARTS OR HELP WITH ASSEMBLY PLEASE CONTACT US AT: simpli-home.
ENTER TO WIN Upload an image of our furniture in your home with a short review to our facebook page for a chance to Win up to $3000 of Simpli Home furniture!!! www.facebook.
IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. SAFETY INFORMATION Identify all the parts and hardware. Do not discard of the packaging until you have checked that you have all of the parts and hardware required. Hardware package may have spare parts. WARNING: This item contains small parts which can be swallowed by children and pets. Keep children and pets away during assembly.
PRE-ASSEMBLY INFORMATION B A TOP QTY 1 MODEL # 3AXCRIV-04 C LEG QTY 2 BOTTOM SHELF QTY 1 MODEL # 3AXCRIV-04 1 3 2 ALLEN KEY BOLT M8 X 20 mm QTY 12 ALLEN KEY QTY 1 LOCK WASHER QTY 12 4 WASHER Ø20 mm QTY 12 NEED HELP? For help with assembly or if you are missing a part, Please call customer service at 1-866-518-0120 ext.
MODEL # 3AXCRIV-04 P1 A B P2 C B 6/13
MODEL # 3AXCRIV-04 STEP 1 2 1 3 4 P1 A B 1. Align one Leg B to Top A by matching the letters P1 to P1 . 2. Use three Allen Key Bolts 1 , three Lock Washers 3 and three Washers 4 to attach Top A and Leg B . 3. Use Allen Key 2 to tighten bolts. Do not over-tighten.
MODEL # 3AXCRIV-04 STEP 2 2 1 3 4 A B P2 1. Align other Leg B to Top A by matching the letters P2 to P2 . 2. Use three Allen Key Bolts 1 , three Lock Washers 3 and three Washers 4 to attach Top A and Leg B . 3. Use Allen Key 2 to tighten bolts. Do not over-tighten.
MODEL # 3AXCRIV-04 STEP 3 A B B C A 1. Place entryway bench assembly on its side on a flat smooth surface. 2. Slide Bottom Shelf C in leg slots.
MODEL # 3AXCRIV-04 STEP 4 2 P1 1 3 4 B A C B 1. Align Bottom Shelf C to Leg B by matching the letters P1 to P1 . 2. Use three Allen Key Bolts 1 , three Lock Washers 3 and three Washers 4 to attach Leg B and Bottom Shelf C . 3. Use Allen Key 2 to tighten bolts. Do not over-tighten.
MODEL # 3AXCRIV-04 STEP 5 4 1 3 2 A C B P2 1. Align Bottom Shelf C to other Leg B by matching the letters P2 to P2 . 2. Use three Allen Key Bolts 1 , three Lock Washers 3 and three Washers 4 to attach Leg B and Bottom Shelf C . 3. Use Allen Key 2 to tighten bolts. Do not over-tighten. Note: Levelers on bottom of legs can be adjusted if floor is uneven.
WARRANTY Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max product. These products have been made to demanding, high-quality standards and are guaranteed for domestic use against manufacturing faults for a period of 12 months from the date of purchase. This warranty does not affect your statutory rights. In case of any malfunction of your product (failure, missing parts, etc.) please contact us at our toll free service line at 1-866-518-0120 ext.
Question, problems, missing parts? Before returning your product please email Customer Support at simpli-home.com/customer-support or call Customer Support at 1-866-518-0120 ext. 262 Monday to Friday between 9 am – 4 pm EST For more information visit us on our website www.simpli-home.com Like us on facebook www.facebook.
