User manual

33
The table below provides details about the section shown in figure above.
Field
Description
Default Priority
The priority level assigned to non-prioritized traffic.
Criteria (1 & 2)
None, Custom, 8021p, TOS, ARP, TCP_8021p, or TCP_TOS
The QoS criteria are applied as follows:
a) Criterion 1 is processed first (and Criterion 2 second)
b) If Criterion 1 is met, Criterion 2 will NOT be applied
Thus, Criterion 2 should be more general than Criterion 1. There are also certain
incompatibilities that arise between these criteria, as outlined in the table below.
If Criterion 1 Protocol is …
Then Criterion 2 can be …
Origin IP / Destination IP
None of these protocols.
TCP with port UDP Protocol, Origin and destination IP
address for UDP packets
UDP with port
TCP Protocol, Origin and destination IP
address for TCP packets
Custom Criterion Configuration
Offset
A decimal ordinal number representing the starting
byte for the pattern in the data packet.
Pattern (hex)
Defines the pattern (8-byte size).
Bitmask (hex)
A bitwise operation applied to the pattern.
Class Offset
A decimal ordinal number representing the starting
byte for the class pattern in the data packet.
Class Bitmask (hex)
A bitwise operation applied to Class Patterns 1-8.
Class Pattern 1-8 (hex)
Defines a class pattern (8-byte size).
Class Priority 1-8
This value ranges from 0 to 7, with 0 being the
lowest priority and 7 the highest priority.
SECURITY STATUS
This section allows you to change (or remove) the configuration password, used
to access the WUI, and perform a factory reset to recover default settings.
