SDB680 INSTALLATION GUIDE TNM-I-E-0046
Aug 14 Page 30 CONFIGURATION TIER III BASE
4 CONFIGURATION OF NEW TIER III BASE STATION
This Procedure should be followed when configuring all new Tier III SDB680 Base Stations
after their initial installation in a new system.
TOOLS, TEST EQUIPMENT AND MATERIALS REQUIRED
The following Tools, Test Equipment and Materials will be required to perform this procedure:
Dummy Load
Personal Computer
Software Applications:
SDMT
Simoco IP Configuration Tool
Notes
(i).
The software applications listed above are available for download on the Simoco
website http://www.simocogroup.com via the Partner Portal. To access the Partner
Portal a Username and Password will be required.
(ii).
To request access to the partner portal please contact your local business
development manager or alternatively contact the relevant Simoco Customer Services
(see Support Page for details).
4.1 SOFTWARE LICENCES
All Tier III Base Stations require a Software Licence in order to operate; these licences can be
obtained from Simoco. If a Tier III Base Station is added to an existing Tier III system, the software
licences for all the base stations on that system will have to be updated.
It is assumed that all the relevant software licences required have been obtained before
commencing this procedure and that they have been uploaded onto a suitable PC.
4.2 SDB680 PREPARATION
WARNING
RF RADIATION. A RF RADIATION HAZARD EXISTS IN THIS
EQUIPMENT. TO AVOID RF INJURY, DO NOT TOUCH THE ANTENNA
WHEN THE TRANSMITTER IS IN USE. DO NOT OPERATE
TRANSMITTER WITH ANTENNA DISCONNECTED. REFER TO EU
DIRECTIVE 2004/40/EC DATED 29 APRIL 2004.
1. Ensure that the SDB680 base stations are securely fitted into the rack and that the power
and antenna cables are connected on the rear panel.
2. On the SDB680 rear panel, connect the Tx antenna socket to a suitable dummy load (for the
50 W base a minimum 60 Watt load can be used provided that it is suitable for use).
3. Connect an Ethernet switch cable to the Ethernet socket.
4. Switch on the power for the system and, in turn, power up each SDB680 base station.
4.3 SDMT INSTALLATION AND PREPARATION
5. Refer to the SDMT User Manual [2] and carry out the following:
