User and Installation Manual The home theater projector cod.46.0331.
BACK LIGHT Turn on the back light LIGHT STAND-BY Switches off to stand-by. 0-9 Keys Switch on from stand-by and allow direct source selection. SOURCE Displays the Source Selection menu. ESCAPE Deactivates the On Screen Display. Not active in this model. Up/Down/Left/Right Arrow keys Navigate through and make adjustments to the On Screen menus. Arrow Up/Down activate Quick menus. MENU Activates the On Screen Display menus. Navigates menu pages. MENU + Activates the On Screen Display menus.
1 INTRODUCTION Congratulations and thank you for choosing a Gran Cinema HT projector, a SIM2 Multimedia SpA product (Fig. 1). ttre comprome d'incende ne pas type N: pour les resque de meme ATTENTIO contre fusible ique par un against la protection caracterist protection remplacer mems et de : for continued CAUTION fire, replace type risk of same with fuse.
A sophisticated proprietary optical system, coupled with a hight performance zoom lens ensures hight contrast images, superior uniformity and edge-to-edge definition. A new 6-segment colour wheel dramatically reduces the so called “rainbow effect” and gives a better contrast, better colorimetry and a lower black level to the image. The DMD™ chip resolution identifies the projector: 1024x576 pixel for HT 280 model and 1280x720 pixel for HT 300 XTRA-H model.
1 3 2 5 8 7 4 6 12 11 13 17 R/C 14 ZOO M RAP 4 G H R ICS GB 15 CON TRO L (R S 23 r I G/Y B/C 2 1 10 ettre mprom e pas co e d'incend e qu ur ne N: po e les res meme typ NTIO ntr ATTE tection co fusible de st e la pro cer par un teristiqu n again rac tectio remplamems ca pro nued et de conti N: for lace IO CAUT fire, rep type risk of h same wit only ing fuse.
2 IMPORTANT SAFETY INSTRUCTIONS ATTENTION: To reduce the risk of electric shock, disconnect the power supply cable on the rear panel before removing the top cover of the projector. Refer to trained, authorised personnel for technical assistance. This symbol indicates the possible electric shock hazard associated with uninsulated live components in the interior of the unit. This symbol indicates the presence of important instructions regarding use and maintenance of the product.
Please follow carefully the warnings listed below, to ensure safe and long term performance of your projector. • Connect the projector to a power supply with a nominal voltage within the following values: 100-240 Vac, 50/60 Hz, earthed (Fig. 3). ettre mprom e pas coue d'incend resq eme type m e de nst tique n agai otectio ed pr 4 250 V T 3.
• Do not touch the surface of the projection lens. • The projector must be positioned on a stable, suitable platform or be installed using a bracket for fixed ceiling or wall installation. Do not rest the projector on the side panels or on the rear panel when in operation. • For installations using a ceiling or wall-mounted bracket, carefully follow the installation and safety instructions provided with the bracket’s literature.
4 INSTALLATION O ZO ZOOM ZO OM FOCUS FOCUS F1 FOCUS F2 FOCUS ZO OM O M FOCUS ZOOM ZO CAUTION: In the case of ceiling or wall mounting using a suspension bracket, follow the instructions carefully and comply with the safety standards you will find in the box together with the bracket.
KEYSTONE 20% ttre comprome d'incende ne pas type N: pour les resque de meme ATTENTIO contre fusible tique par un against la protection caracteris protection remplacer mems et de : for continued CAUTION fire, replace type risk of same with fuse. only and rating R/Cr L ICS ZOOM RGB G/Y 5 DIGITA 3 AUDIO OUT INPUT 4 GRAPH B/Cb 2 OL (RS 232) CONTR 1 HV C-SYNC Fig. 11 Fig.
which is undesirable for a large audience. Preferably, use a screen with black, non-reflecting borders, which will perfectly frame the projected image. Avoid light shining directly on the screen during projection as this will reduce contrast and black level detail on the projected image. For the true cinema experience best results are achieved with little or no ambient light.
memorising the input selection at the time of switch-off. The fans will continue to work until the lamp has cooled down (red and green LEDs flashing) and will stop automatically after this period. SWITCHING OFF AND RETURNING TO STAND-BY By remote control: press By keyboard: press key LED INDICATORS When switching off, the projector goes in to stand-by STATE The LED indicators, located in the top-rear of the projector, provide information about the state of the projector (see table below).
Frequency of between 32-80 kHz and a Vertical frequency of between 48-100 Hz. Computer Resolutions of VGA, SVGA, XGA, SXGA and UXGA can be displayed. COMPOSITE VIDEO INPUT B/C 2 CON 1 TR S OL (R 232 b ) R/C ce IO CAUT fire, replatype risk of th same wi only ting fuse. and ra r HV ZOO RA 4 G M PHIC SR GB B/C 2 TR CON 1 OL (R S 23 I G/Y 3 DM 5 H IO AUD OUT b 2) HV CVBS COMPOSITE VIDEO Fig.
SCART to RCA connector adapter cable, an RGB video signal from a source equipped with an SCART connector can be connected to this input. Component signals are connected to inputs Y, Cr and Cb, taking care to observe the correspondence with the outputs on the source. The video signals that can be connected to this input can have horizontal scanning frequencies of 15 kHz (standard video resolution), 32 kHz, or higher (progressive scanning video, high definition video).
its output can be set with the “Screen control” adjustment in the “Aspect” menu. This output allows reduction in the area of a 16:9 screen, into a 4:3 format, by activating a screen masking system (refer to screen manufacturer for further information). R/C ZOO M 4 G HIC RAP SR GB 2 1 CO OL NTR (RS 232 I G/Y B/C RS232 INTERFACE CONNECTOR ace TIO CAU fire, repl type risk of ith same .
8 REMOTE CONTROL Insert the batteries, taking care to match the polarity, as indicated in the battery recess of the remote (Fig. 24). - + + - + + - The remote control sends commands to the projector via infrared signals. It is possible to control the projector by pointing the remote control at the screen; the sensor at the front of the projector will pick up the reflected infrared commands. (Fig. 25). four 1.5V AAA alkaline batteries DVI C-SYNC LIGHT Fig.
9 ON SCREEN MENU SOURCE SELECTION The input selection menu (Inputs) is called by pressing 0 on the remote control and, when no other menu is displayed, using the and keys on the keypad. To select an input, scroll the list with the and keys until the desired input is highlighted, then press . Display of the input selection menu is terminated by pressing the ESC key, or when the time allowed for displaying the onscreen menu has lapsed (set in the Set-up Menu).
Other adjustments (marked by the < symbol) provide submenus, which appear as a superimposed window in which the selection is made with the / keys (Fig. 28). . Image Aspect Color Temperature Gamma Correction Overscan Position Y/C Delay 1 1 Fig. 28a Image Aspect Color Temperature Gamma Correction Overscan Position Y/C Delay 1 Normal Anamorphic Letterbox Panoramic Pixel to pixel User 1 User 2 User 3 Fig.
CINEMA MODE In AUTO the deinterlacer recognises if the video signal source is a movie film (obtained from a Telecine device with 3:2 or 2:2 pull-down) and applies a deinterlace algorithm optimised for this type of signal. If the video signal source is not identified as a film, or if you select NO the deinterlacer applies a Motion compensated algorithm optimised for video camera signals. VIDEO TYPE Activates a filter to improve stability of pictures from video recorders.
IMAGE This menu features adjustments relating to picture position, aspect ratio, etc. ASPECT This adjustment allows you to change the dimensions and aspect ratio (relationship between width and height) of the displayed image. There are five preset aspects available and three personalised aspects (with user-settable parameters). You can select a different aspect for each source: the selected aspect ratio will be automatically called the next time the relative source is called.
the system checks the input signal and automatically sets the most suitable values. However, if the image is not perfectly centralised it may prove useful to request the system to repeat the input signal analysis and image positioning, calling the automatic control procedure from the AUTO button on the remote control or keypad. When this procedure is called it is helpful to have a white or light coloured background on the screen in the current picture.
SETUP The setup menu contains less frequently used adjustments that may be required during installation (e.g. On Screen Display language selection or the display of Test Patterns). If the projected images needs to be centred horizontally, the manual lens shift adjustment allows the projected image to be moved vertically, up or down, in relation to the centre of the screen; the maximum adjustment being equal to half the height of the image in either direction (Fig. 31).
In the initial phase of installation the configurable keys (F1, F2) serve as optical zoom and optical focus (Fig.32). POWER ON If active (AUTO) allows to power up the system directly from the power feeder, once the initializing phase is completed. If not active (STAND-BY) once the initializing phase is completed the system remains in a stand-by mode waiting to receive the power on command from the remote control or the key pad.
The text insertion mode remains the same if text is being inserted for the first time or if a previously inserted name is being edited. The letter insertion can be done in any available position (represented by horizontal lines). Use the and keys to move between letters either left or right respectively. Press the numeric key matching the letter (Fig. 34), the first click of the key selects the first letter, the second click the second letter and so on.
The operations that can be performed on each memory selected are described here below. MEMORIES The main parameters of the image may be saved in distinct groups of values (known as ‘Memories’); these parameters can subsequently be applied all together by way of a single command.
RESTORE CURRENT SETTINGS On entering the ‘Memories’ menu, a copy of the current settings is saved in a temporary menu (labelled with 0 - AUTO). Once one or more memories have been recalled, you can restore the settings that were effective at the moment the Memories menu was accessed by selecting 0 - AUTO. However, this operation must be completed before the ‘Memories’ menu page disappears (30 seconds after the last operation commanded from the remote control or the keypad).
11 TROUBLESHOOTING GUIDE No power (Green and red LED are OFF) - Check the power switch at the rear: it must be in position I. - Check if the power cable has been connected correctly to a working socket. - Check the power socket fuse, at the rear of the projector. - Replace the fuse on the mains socket with an identical type (T 3.15A H) (Fig. 2). - Should the problem persist, seek authorised technical assistance.
Video Image showing colour misalignment on vertical details - Verify compatibility of video/graphic signals with technical specifications of your projector. - Adjust Y/C Delay settings in the Image Adjustments / Advanced Settings to reduce colour misalignment. For best results use an external colour bar test pattern source. Remote control does not work - Check the batteries and for correct polarity.
A TECHNICAL SPECIFICATIONS OPTICAL HT 280 OPTICAL HT 300 XTRA-H Projection system: optical engine based on 1 DMD™, sealed housing, dusty proof Projection system: optical engine based on 1 DMD™ HD2+ chip, sealed housing, dusty proof DMD™ panel: resolution 1024x576 pixel DMD™ panel: resolution 1280x720 pixel Brightness uniformity: 10% above or below the average Brightness uniformity: 10% above or below the average Contrast ratio: > 2300:1 (full On / full Off) Contrast ratio: > 2800:1 (full On
ELECTRICAL Input Signals: GENERAL CVBS on RCA/Phono type connector S-VHS on Mini-DIN connector RGBHV on DB15HD connector RGBS / YCrCb on RCA/Phono type connector HDMI™ Horizontal frequency: from 15 to 80 kHz (up to to UXGA format @ 60 Hz) Vertical frequency: 48-100 Hz Video standards : automatically selected (PAL B,G,H, I, M,N,60, SECAM, NTSC 3.58, 4.
102 174 74 352 B DIMENSIONS 318 unit: mm (inches) C PROJECTION DISTANCES H Follow the table below to determine the optimal projection distance “L” between the screen and the center of the lens. This will help you to obtain the desired screen size.The manual lens shift adjustments allows the projected image to be moved vertically, up or down, in relation to the centre of the screen (Fig.37b).
Projection distance table HT 300 XTRA-H Screen Screen size width 16/9 Min projection distance (diagonal) min L Max projection distance Hmax max L in. m in. m ft. in. m ft. in.
Projection distance table HT 280 Screen Screen size width 16/9 Min projection distance (diagonal) min L Max projection distance Hmax max L Hmax in. m in. m ft. in. m ft. in. 50" 1,1 43” 2,5 8’ 1” 0,4 1’ 5” 3,4 60" 1,3 51” 3,0 9’ 7” 0,5 1’ 9” 4,1 2’ 0” 4,8 15’ 7” 0,8 2’ 9” 2’ 4” 5,5 17’ 9” 1,0 3’ 2” 70" 1,6 63” 3,5 11’ 3” 0,6 80" 1,8 71” 4,0 13’ 0” 0,7 m ft. in. m ft. in.
D ON SCREEN MENU LAYOUT Picture Video • S-Video [NTSC] YCrCb15kHz RGBS 15kHz Brightness Contrast Color Tint Sharpness Filter Cinema Mode Video Type Noise reduction Video • S-Video [PAL, SECAM] Brightness Contrast Color Sharpness Filter Cinema Mode Video Type Noise reduction Not active YCrCb Brightness Contrast Sharpness Sharpness Mode Brightness Contrast Color Tint Sharpness Sharpness Mode Auto Flesh tone correction RGBS RGB Grafico HDMI™ Manual On Off Value Flesh tone correction On Off Imag
Setup Orientation Keystone Lens Power ON Test patterns Initial settings Zoom Focus Auto Stand-by English Italiano Français Deusch Español Português Menu Language Source list F1/F2 keys Source info OSD background OSD Position OSD Timeout Floor Floor-rear Ceiling Ceiling-rear Horizontal Horizontal F1 F2 Yes No Zoom Focua Magnification Blank Color temperature Gamma correction 1 VIDEO 1 2 S-VIDEO 2 3 COMPONENT / RGBS 3 VIDEO 1 S-VIDEO 2 COMP RGB 3 4 GRAPHICS RGB 4 GRAPH RGB 4 5 HDMI 5 HDMI 5 Act
Memories Memories 0 Auto 1 S MEMORY 1 2 S MEMORY 2 3 S MEMORY 3 34 Save current settings Save initial settings Rename Edit memory name ___________ Cancel - Confirm + ()?@ 1 ABC 2 DEF 3 GHI 4 JKL 5 MNO 6 PQRS 7 TUV 8 WXYZ 9 0
INDEX 1 INTRODUCTION 1 Source selection 15 2 IMPORTANT SAFETY INSTRUCTIONS 4 Main menu 15 3 PACKAGING AND CONTENTS 6 Picture 16 4 INSTALLATION 7 Image 18 5 SWITCHING ON AND OFF THE PROJECTOR 9 Set up 20 Switch on from stand-by 9 Menu 21 Switching off and returning to stand-by 10 Memories 23 10 Info 24 Composite video input 11 Quick menus 24 S-VIDEO Input 11 Messages 24 VGA input 11 10 CLEANING AND MAINTENANCE 24 RGB/YCrCb Input 11 11 TROUBLESHOOTING GUIDE 25
SIM2 Multimedia S.p.a. • Viale Lino Zanussi, 11 • 33170 Pordenone - ITALY Phone +39.434.383.253-256 • Fax +39.434.383260-261 www.sim2.com • e-mail: info@sim2.it SIM2 USA Inc. • 10108 USA Today Way • 33025 Miramar FL - USA Phone +1.954.4422999 • Fax +1.954.4422998 www.sim2usa.com • e-mail: sales@sim2usa.com SIM2 Deutschland GmbH • Gewerbepark, 17 D-35606 Solms Phone 0800.800.7462 • Fax 0800.900.7462 www.sim2.com • e-mail: info.de@sim2.it SIM2 UK LTD • Steinway House Worth Farm, Little Horsted Nr.
