A Specifications
This device has been designed to operate with the antennas listed below, and having a maximum
gain of 3 dBi (sBridge) and 6 dBi (eBridge). Antennas not included in this list or having a gain
greater than 3 dBi (sBridge) or 6 dB (eBridge), are strictly prohibited for use with this device. The
required antenna impedance is 50 ohms.
C-Tick Level 3 (Radiated/Conducted Emissions Compliance AS/NZS4268,
AS/NZS4778)
The NIC is compliant to C-tick testing for radiated and conducted emissions in compliance with
Australian Communications Authority (ACA) adopted standards from CISPR, CENELC, and IEC.
The sBridge uses a 1W EIRP, 900 MHz, FHSS radio.
The C-Tick EIRP mark is filed under number N1571 for Silver Spring Networks.
Silver Spring Networks NIC, FCC IDs:
OWS-NIC515 IC: 5975A-NIC515 (sBridge)
OWS-NIC506, IC:5875A-NIC506 (eBridge)
The NIC515 must be professionally installed by a properly trained technician. Improper
installation could void the user's authority to operate the equipment.
The device complies with Part 15 of the FCC rules. Operation is subject to the following two
conditions:
1. The device may not cause harmful interference.
2. The device must accept any interference received, including interference that may cause
undesired operation.
Antenna
The antenna of this transmitter must not be co-located or operating in conjunction with any
other antenna or transmitter.
The device should be installed so that people will not come within 20 cm (8 in.) of the antenna.
This equipment has been tested and found to comply with Part 15 of the FCC Rules. This
equipment generates, uses and can radiate radio frequency energy, and if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Table 21. Available antennas for Silver Spring Network bridges
SSN Antenna Part # Description
315-00012 Rev. 5 JPole antenna
315-000002 Rev. A sBridge: Rubber Duck, 3dBI maximum gain, SMA Female, Antenna
eBridge: Rubber Duck, 6dBI maximum gain, SMA Female, Antenna
