Bridges Hardware Guide Silver Spring Networks 21
A Specifications
All RS-232 receptacles are standard DB-9 receptacle DCE pinout.
Table 11. eBridge DB-9 Interface Definition
Pin# Signal Direction Description
1 DCD Output Data Carrier Detect
2 TXD Output Transmit Data
3 RXD Input Receive Data
4 DTR Input Data Terminal Ready
5 GND -- Signal Ground
6 DSR Output Data Set Ready
7 RTS Input Request To Send
8 CTS Output Clear To Send
9 RI Output Ring Indicator
Table 12. eBridge RJ-45 Hub Interface Definition
Pin # Signal Direction Description
1 RX+ (+V1) Input Receive Data + (+ Voltage Supply type 1)
2 RX- (+V1) Input Receive Data - (+ Voltage Supply type 1)
3 TX+ (-V1) Output Transmit Data + (- Voltage Supply type 1)
4 No Connect (+V2)
–
(+ Voltage Supply type 2)
5 No Connect (+V2)
–
(+ Voltage Supply type 2)
6 TX- (-V1) Output Transmit Data - (- Voltage Supply type 1)
7 No Connect (-V2)
–
(+ Voltage Supply type 2)
8 No Connect (-V2)
–
(+ Voltage Supply type 2)
