User Manual
Wireless IR Signal
Extender Kit
Quick Start Guide
04-1154A
P/N: CE-RC0111-S1
July, 2018 Copyright © 2018 by SIIG, Inc. All rights reserved.
Application
Support
For more info or tech support
http://www.siig.com/support
FCC RULES: TESTED TO COMPLY WITH FCC PART 15, CLASS B
OPERATING ENVIRONMENT: FOR HOME OR OFFICE USE
FCC COMPLIANCE STATEMENT:
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
Paring conguration instruction
1. Power via the USB power cable to
connect with power supply.
2. Long press RX’s” Lock ID” button up to
4s until it enters into paring mode (the
status of IR indicator from keeps on to
ashespersecond)
3. Long press TX’s” Lock ID” button up to
4s until TX is paired with RX (the status
ofIRindicatorfromontoo).
NOTE:
1. TX and RX must pair with each other
before using
2. Transmissiondistancewillbedierent
due to the environment
3. Wall, brick or glass will shorten the
signal cover range or cause signal loss
4. IR sensors are built into the units, use of
the IR extensions cables are optional
and needed only to allow convenient
placement and enhance IR function
