User Manual

1. IR IN port: Connect with IR receiver

cable,receiver IR signal

2. IR indicator: It’s turns on when using

the remote control

3. IR receiver head: Built-in IR signal

receiver head

4. Power inout: Connect with the USB cable

5. Lock ID button: It is used for TX & RX

pairing.

Features

• Wide IR frequency 20 to 60 KHz compatible

• Long wireless distance up to 200m.

• Include a IR transmitter and a IR receiver,

working as a pair.

Package contents

• IR Wireless Transmitter

• IR Wireless Receiver

• USB Power cable x2

• IR blaster extension cable

• IR receiver extension cable

• Quick Start Guide

Layout

Transmitter

Dear Valued Customer

(JUST WANTED YOU TO KNOW)

WE REALLY

APPRECIATE

YOUR PURCHASE

~thank you~

1. IR OUT port: Connect with IR blaster

cable,send IR signal

2. IR indicator: It’s turns on when using

the remote control

3. IR emitter head: Built-in IR signal

emitter head

4. Power inout: Connect with the USB cable

5. Lock ID button: It is used for TX & RX

pairing.

Receiver

PAGE 1
Features Dear Valued Customer (JUST WANTED YOU TO KNOW) WE REALLY APPRECIATE YOUR PURCHASE ~thank you~ • Wide IR frequency 20 to 60 KHz compatible • Long wireless distance up to 200m. • Include a IR transmitter and a IR receiver, working as a pair. Layout Receiver Transmitter Package contents • • • • • • IR Wireless Transmitter IR Wireless Receiver USB Power cable x2 IR blaster extension cable IR receiver extension cable Quick Start Guide 1.
PAGE 2
Paring configuration instruction 1. 2. Power via the USB power cable to connect with power supply. Long press RX’s” Lock ID” button up to 4s until it enters into paring mode (the status of IR indicator from keeps on to flashes per second) 3. Long press TX’s” Lock ID” button up to 4s until TX is paired with RX (the status of IR indicator from on to off). Application NOTE: 1. 2. 3. 4.
