Installation guide

3
Hardware Kit
a
b
c
ehf
g
(x4) M6x12 bolt
(x4) M5x12 bolt (x4) M8x16 bolt
(x4) M5x30 bolt (x4) M6x35 bolt (x4) M8x40 bolt
(x6) Concrete anchor
ki
j
(x4) M6/M8 washer
(x6) Lag bolt
o
l
(x4) M6/M8 spacer
n
pm
(x4) M4x30 bolt
(x4) M4x12 bolt
(x1) Wall plate
(x1) Right monitor bracket
(x1) Left monitor bracket
(x4) M5 lock washer
(x4) M4 lock washer
(x4) M6 lock washer
(x4) M8 lock washer
qr
st
(x8) M4/M5 washer
(x6) Lag bolt washer
(x4) M4/M5 spacer
vw
x
(x1) Bubble level
