User`s guide

Signamax Gigabit Ethernet Media Converter
8 User’s Manual
Specifications
Applicable Standards IEEE 802.3 10BaseT
IEEE 802.3u 100BaseTX
IEEE 802.3ab 1000BaseT
IEEE 802.3z 1000BaseSX/LX
Fixed Ports
10/100/1000BaseT/TX to
1000BaseSX/LX/BX:
1 TX port
1 FX port
Speed
10BaseT
100BaseTX
1000BaseT/SX/LX/BX
10/20Mbps for half/full-duplex
100/200Mbps for half/full-duplex
2000Mbps for full-duplex
Forwarding Rate
10BaseT
100BaseTX
1000BaseT/SX/LX/BX
14,880pps for 10Mbps
148,810pps for 100Mbps
1,488,100pps for 1000Mbps
LED Indicators
PWR; LFS; LNKC; Copper Port Speed; LNKF; FDX
Dimensions
3.16” (W) × 4.3” (D) × 0.94” (H)
(80.3mm (W) × 109.2mm (D) × 23.8mm (H))
Weight
0.33lb. (150g)
Power
External power adaptor
0.23A @ 12VDC
Power Consumption
2.76W Max.
Operating Temperature
32
℉
to 122
℉
(0
℃
to 50
℃
)
Storage Temperature
14
℉
to 158
℉
(-10
℃
to 70
℃
)
Humidity
5%-95% non-condensing
Emissions
FCC part 15 Class A, CE Mark Class A
