Introduction of SDG1000 Series
The manual covers the following 5 types of SDG1000 Series
Function/Arbitrary Waveform Generators: SDG1005, SDG1010, SDG1020,
SDG1025, SDG1050.
SIGLENT SDG1000 Series Function/Arbitrary Waveform Generators adopt
the direct digital synthesis (DDS) technology, which can provide stable,
high-precision, pure and low distortion signals. Its combination of excellent
system features, easiness in usage and versatile functions makes this
generator a perfect solution for your job now and in the future.
SDG1000 Series Function/Arbitrary Waveform Generator has a clear and
simple front-panel. The user-friendly panel layout and instructions, versatile
terminals, direct graph interface, built-in instructions and help system have
greatly simplified the operation process, with the help of which, users do not
have to spend a great deal of time learning and familiarizing the operation of
the generator before they can use it proficiently. The built-in AM, FM, PM,
ASK, FSK and PWM modulation functions generate modulated waveforms at
ease, without the help of a separate modulating source. USB I/O is a
standard accessory, while GPIB is optional. Remote instructions meet the
SCPI specification requirements.
From the characteristics and specifications given below, you will understand
how SDG1000 can satisfy your requirements.
