WARNING
Slide is under spring tension. Maintain positive control during slide removal
to prevent damage or injury. Wear eye protection.
8.1 Pistol Disassembly
1. Unload the pistol (see section 6.0 “Unloading the Pistol”).
2. Manually pull the slide until the slide stop notch is aligned with the slide
stop tab.
3. Retract the slide stop from the frame. Note: the slide stop is held captive
by the slide stop spring.
4. Move the slide assembly forward until removed from the frame.
