Siemens Electronic connection for valves with magnetic actuator CA1N4591en
Building Technologies 2019-02-28
Disposal
The device is considered electrical and electronic equipment for disposal in
terms of the applicable European Directive and may not be disposed of as
domestic garbage.
• Dispose of the device through channels provided for this purpose.
• Comply with all local and currently applicable laws and regulations.
Warranty
Application-specific technical data must be observed.
If specified limits are not observed, Siemens Switzerland Ltd will not assume
any responsibility.
Technical data
ZM../A
ZM110, ZM111,
ZM210
1)
Power supply
Extra low-voltage only (SELV, PELV)
Operating voltage
2)
AC 24 V + 15 % / -10 %
Frequency
50…60 Hz
Max. apparent power S
NA
ZM1..
ZM2..
≤ 40 VA
≤ 120 VA
Signal inputs
Positioning signal
ZM100/A, ZM101/A, ZM200/A
DC 0…10 V or
DC 0…20 V Phs
ZM120/A, ZM121/A, ZM220/A
DC 4…20 mA or
DC 0…20 V Phs
ZM110, ZM111, ZM210
DC 0…20 V Phs
Input resistance DC 0…10 V
> 90 k
Input resistance DC 4…20 mA
< 150 Ω
Electrical connections
Cable entry point
2 x PG11
PG11
Connecting terminal
screwing terminal for 4 mm
2
wire
Min. wire cross-section
0,75 mm
2
Norms and directives
Electromagnetic compatibility
(Application)
For residential, commercial and industrial
environments
Product standard
EN 60730-x
EU Conformity (CE)
CA1T4591xx
3)
Electrical safety
EN 60730-1
Housing protection
refer „Type summary“, page 2
Environmental compatibility
Environmental declaration
contains data on environmental-compatible
product design and assessment (RoHS
compliance, compositions, packaging,
environmental benefits and disposal)
1)
While stocks last
2)
Electronic connection ZM../A used with DC 0…20 V phase cut signals: Do not connect AC 24 V.
3)
The documents can be downloaded from http://siemens.com/bt/download
