Environmental Declaration

EPD - Type II
Based on ISO 14021
CuZn; no coating haousing xx ITF xx WMZ5 variant
CuZn; no coating socket tepmperatur sensor 5g
CuZn; no coating TF-Screw-half-shell 20g
CuZn; no coating plate 6,1x8,8x0,5 3g
Stahl >5% legiert; galvanized screw 1g
Li-MnO2 (CR AA) 1st battery / accumulator 22g
Li-MnO2 (2/3CR AA) 1st battery / accumulator 16g
glas LCD Qheat5 8g
Cu + PVC temperature sensor cold 5x45x800 20g
Cu + PVC temperature sensor hot 5x45x800 35g
FR4; TBBA; solder SnAgCu PCB Qheat5 33g
FR4; TBBA; solder SnAgCu PCB Qmodule5.5 heat 7g
*Variant parts list
[g]
haousing xx ITF xx WMZ5
Comments
WFN681-G000H0
378
WFM682- G000H0 WFN683-L000H0
378
WFM681- G000H0
314 464
WFM683-L000H0 WFN682-G000H0
314 464
EU-directive 2011/65/EU (RoHS)
The device does not contain substances in concentrations and applications banned under the EU RoHS Directive.
Others
The device is classified as waste electronic equipment in terms of the European Directive 2012/19/EU (WEEE) and must
not be disposed of as unsorted municipal waste. Regarding disposal, use the systems setup for collecting electronic
waste.
Observe all local and applicable laws.
Disposal
PCBAs (Printed Circuit Board
assembled)
Metals
A5W00042720-A 27.11.2017
The device contains the following substances of the candidate list according to Article 59 (1, 10) of the regulation (EC) No. 1907/2006 concerning the
Registration, Evaluation, Authorisation and Restriction of Chemicals (REACH) in concentrations above 0.1 % w/w.
1,2-dimethoxyethane; ethylene glycol dimethyl ether (EGDME), CAS-Nr.CAS-Nr. 110-71-4
(Status according to the creation date of this document.)
Please contact your local Siemens branch office to get further information on environmental aspects and disposal.
Environmental benefits
The heat meter is used for measuring heat energy. The combined measurement of heat and cold energy is possible. The main areas of application are in
central heating systems where the heating energy is outputted individually to different consumers.
Q modules are separate add
-
on modules and impulse adapters with which you can extend the performance capabilities of our measuring devices They
Legal Disclaimer: This declaration is for information purpose only.
QUNDIS GmbH therefore does not assume liability for any error or for any consequences which may arise from the use of this information to the maximum extent under the
law.
This Environmental Product Declaration does not constitute a guarantee of the composition of a product, neither does it guarantee that the product will retain a particular
composition for a particular period.
Regulation (EC) No. 1907/2006 (REACH)
The device is halogen-free with exception of:
PCB (TBBA); cable tempertur sensors; cable for data transmission ; battery / accumulator
Restricted Page 2/2
