Example:
Type
Stock number
Product name
Quantity
VVI46.15/3
S55249-V113
2-port zone valve, PN16 DN15,
k
vs
2.15
1
Delivery
The valves and actuators are delivered in separate packaging.
Order actuator SUE21 separately.
Revision number
See Revision numbers [➙ 8].
Equipment combinations
Valves
Motoric actuators
SUE21
ΔP
max
[KPa]
ΔP
S
[KPa]
VVI46.15/3…20/3
400
400
VVI46.25/3
300
300
Δp
max
: Maximum permissible differential pressure across the valve's control path, valid for the entire actuating
range of the motorized valve
Δp
S
= Maximum permissible differential pressure at which the motorized valve will close securely against the
pressure (close off pressure)
Actuator overview
Actuator
Operating voltage
Positioning
Positioning force
Data sheet
Signal
Time
SUE21
AC 230 V
3-wire
on / off
(SPST
1)
)
12 s
170 N
A6V11866674
1)
SPST = single pole, single throw
4832Z01
Product documentation
Topic
Title
Document ID:
Mounting and installation
Mounting instructions
1)
A6V11841845
Environmental compatibility
Environmental declarations
A5W00070709
1)
The mounting instructions is enclosed in product packaging.
