User Manual

• Actuators for every control requirement
• Straightforward planning due to broad
actuator range
• Efficient plant control and quick troubleshooting
thanks to additional functions
 | Actuators for PICVs

Acvatix PICVs for every application
PN class Connection DN Volumetric flow
PN 25 Flange 50...150
PN 16 Flange 50...150
PN 25 Internally threaded 15...50
PN 25 Externally threaded 10...32
PN 10
Externally/internally
threaded
10/15
l/h
10
30 50
100
200 500
1000
2000 5000
10000
50000
100000
20
200000
m
3
/h 1 2 3 4 6 10 20 30
50
10 0 200
VPF53..
VPF43..
VPI46..
VPP46..
VPD../VPE..

