Neck

Indications:

For soft tissue spiral studies in the cervical region, e.g.,

tumors, lymphoma, abscesses etc.

A typical range of 20 cm will be covered in 42 sec.

Neck

kV 130

Effective mAs 70

Rotation time 1.0 sec

Slice collimation 2.5 mm

Slice width 5.0 mm

Feed/Rotation 5.0 mm

Pitch Factor 1.0

Increment 5.0 mm

Kernel B50s

CTDIVol

7.55 mGy

Effective dose Male: 1.79 mSv

Female: 1.87 mSv

Contrast medium IV injection

Start delay 45 sec.

Flow rate 2.0 ml/sec.

Total amount 120 ml
