212

Children

ThoraxHRSeq_Child

Indications:

Sequence mode for High Resolution lung studies, e.g.,

interstitial changes of the lung parenchyma, etc.

A range of 20.1 cm is predefined.

* The conversion factor for a 7-year-old child, and a

scan range of 201 mm was used.

ThorHRSeq

kV 130

Effective mAs 70

Rotation time 1.0 sec

Slice collimation 1.0 mm

Slice width 1.0 mm

Feed/Scan 10.0 mm

Kernel U90s

CTDIVol 1.51 mGy

Effective dose Male: 1.02 mSv*

Female: 1.21 mSv*
