180

Specials

HeadTrauma

A spiral mode for emergency head studies with a max.

FoV of 500 mm. A typical scan range of 40/80 cm will

be covered in 23/27 sec.

Base Cerebrum

kV 130 130

Effective mAs 110 110

Rotation time 1.5 sec 1.0 sec

Slice collimation 1.5 mm 2.5 mm

Slice width 3.0 mm 8.0 mm

Feed/Rotation 3.0 mm 5.0 mm

Pitch Factor 1.0 1.0

Increment 3.0 mm 8.0 mm

Kernel H31s H31s

CTDIVol 25.05 mGy 25.05 mGy

Effective dose Male:

0.37

mSv

Female:

0.51 mSv

Male:

0.70

mSv

Female:

0.86 mSv
