Spine

141

Spine 2

nd

reconstruction

kV 130

Effective mAs 120

Rotation time 1.5 sec

Slice

collimation

2.5 mm

Slice width 3.0 mm 3.0 mm

Feed/Rotation 5.0 mm

Pitch Factor 1.0

Increment 3.0 mm 2.0 mm

Kernel B31s B60s

CTDIVol 12.94 mGy

Effective dose Male:

2.94 mSv

Female:

6.75

mSv
