Spine

137

C-Spine 2

nd

reconstr.

kV 130

Effective mAs 90

Rotation time 1.0 sec

Slice collimation 1.5 mm

Slice width 3.0 mm 2.0 mm

Feed/Rotation 3.0 mm

Pitch Factor 1.0

Increment 3.0 mm 1.5 mm

Kernel B50s B50s

CTDIVol 9.70 mGy

Effective dose Male:

2.02

mSv

Female:

2.07

mSv
