Pelvis

129

Hints

• In case of 3D study only, images should be recon-

structed with at least 50% overlap in image recon-

struction and kernel B20s.

• If only one side is examined, it is advisable to enter

the side in the comment line on the Routine card.

Hip 2

reconstr.

kV 130

Effective mAs 70

Rotation time 1.0 sec

Slice collimation 1.5 mm

Slice width 3.0 mm 2.0 mm

Feed/Rotation 3.0 mm

Pitch Factor 1.0

Increment 3.0 mm 1.5 mm

Kernel B70s B70s

CTDIVol 7.55 mGy

Effective dose Male:

1.78

mSv

Female:

1.66

mSv
