Diagnostic software for -> PROFIBUS with which the traffic on the ->
network can be recorded and analyzed.
Synonym for -> bus segment.
Services provided by a communication protocol.
A -> bus parameter for -> PROFIBUS. The setup time specifies the
minimum interval on the sender between receiving an acknowledgment
and sending a new call frame.
Siemens Network and Communication. Product name for -> Siemens
networks and network components.
A bus parameter for -> PROFIBUS. The slot time (TSL) is the time
during which the sender of a -> frame waits for the acknowledgment
from the receiver before detecting a timeout.
A station is identified by an -> PROFIBUS address in the ->
PROFIBUS network.
A subnet is part of a -> network whose -> bus parameters (for example
-> PROFIBUS addresses) must be matched. It includes the bus
components and all attached stations. Subnets can, for example, be
connected together by -> gateways to form a network.
A -> system consists of several subnets with unique -> subnet
numbers. A subnet consists of several ->stations with unique ->
PROFIBUS addresses.
A -> system consists of several -> subnets with unique subnet
numbers.
The SYNC mode is a DP mode in which several or all -> DP slaves
transfer data to their process outputs at a certain time. The time at
which the data is transferred is indicated in the SYNC command (a
control command for synchronization).
All the electrical equipment within a system. A system includes, among
other things, programmable logic controllers, devices for operation and
monitoring, bus systems, field devices, actuators, supply lines.
A -> bus parameter for -> PROFIBUS. The token represents the right
to transmit for a -> station on PROFIBUS. A station compares the
actual token rotation time it has measured with the target rotation time
and depending on the result can then send high or low priority frames.
SCOPE for
PROFIBUS
Segment
Services
Setup time
SIMATIC NET
Slot time
Station
Subnet
Subnet number
SYNC mode
System
Target rotation
time
