Technical data

Description of the Architecture
Introduction to PROFIBUS on Industrial PC
C79000-G8976-C068
15
3.4 Network Architecture
PC/
workstation
PC/PG with
SIMATIC S5 SIMATIC S7
SCOPE for PROFIBUS
PC/PG with
DP slave DP slave FMS slave
with PROFIBUS CP
PROFIBUS CP
and PROFIBUS CP
PROFIBUS
Figure 3.4 Network Architecture of PROFIBUS
PC and PROFIBUS
