Technical data
14.1 General Specifications
SIMATIC IPC627C
118 Operating Instructions, 11/2010, A5E02669068-02
General specifications
PROFINET
*6
3 x RJ-45 connection, CP 1616 compatible onboard
interface based on ERTEC 400, 10/100 Mbps isolated
*5
Ethernet
∗5 ∗6
Wake on LAN and Remote Boot are supported
Ethernet 1: Intel 82577 L, capable of teaming
capable of AMT, supports jumbo frames up to 4088 bytes
Ethernet 2: Intel 82574 L, capable of teaming
supports jumbo frames up to 9014 bytes
COM1 Serial port 1
9-pin Cannon socket
Compact Flash Slot for Compact Flash Card
Status displays on the device
DVD/CD access (to CD drive if installed)
2 x7 segment display (for BIOS post codes)
2x two-color alarm LEDs
1x LED for Profinet (optional)
*1
Restrictions for DVD burner: Burner is only permitted with ambient temperatures of +5°C
to +40°C
*2
Limitation with DVD burner drives:
10 to 58 Hz: 0.019 mm / 58 to 500 Hz: 2.5 m/s
2
Burner can only be operated in an interference-free environment
*3
Restriction for installation with vertical mounting kit
Vibration: 10-58 Hz: 0.0375 mm / 58-500 Hz: 4.9 m/s
2
Shock resistance: 25 m/s
2
, 30 ms
*4
Optional product variant
*5
Electrical isolation within the safety extra-low voltage circuit (SELV)
∗6
For unique labeling, the LAN interfaces are numbered on the housing. The numbering by
the operating system can differ.
