Technical data
14.1 General Specifications
SIMATIC IPC627C
Operating Instructions, 11/2010, A5E02669068-02
117
General specifications
Free expansion slots 1 x PCI 290 mm long and 1 x PCI 185 mm long
or
1 x PCI 290 mm long and 1
x PCI Express x16 185 mm long
Max. permissible power consumption
per PCI/PCIexpress slot
5 V / 2 A or 3.3 V / 3 A, 12 V / 1 A, -12 V / 0.05 A
The accumulated power consumption (all slots) may not
exceed 30 W
Disk drives
Hard disk drive 3.5" / 2.5" serial ATA, see ordering documentation for the
hard disk capacity
- 3 Gbps data transmission rate
- supports NCQ (Native Command Queuing;
SATA II property)
Flash memory CompactFlash card
1 x Solid State Disk
DVD burner
∗2
Serial ATA, See order documentation for features
Graphics
Graphic controller Intel® HD Graphics Controller,
2-D and 3-D engine integrated in chipset
Graphics memory Dynamic Video Memory Technology
(uses up to 256 MB of RAM)
Resolutions/frequencies/colors CRT:
Max. 1280x1024 at 100 Hz / 32-bit color depth
Max. 1600x1200 at 60 Hz / 32-bit color depth
Maximum resolution:
2038x1536 at 75 Hz / 16-bit color depth
LCD via DVI-I: 1600x1200 at 60 Hz / 32-bit color depth
Interfaces
DVI-I Port for external CRT / LCD monitor
USB External: 4 x USB 2.0 on the port side
(max. 2 can be simultaneously operated as high current)
There are 3 USBs available internally: 1 x USB 2.0 high
current + 1x USB 2.0 low current on a 10-pin male
connector, 1 x USB 2.0 low current for internal USB
stick/dongle
Front panel ports: 1 x USB 2.0 high current
1 x USB 1.1 high current
PROFIBUS / MPI interface
∗4
- Transmission speed
- Operating mode
- Physical interface - Memory address
space
- Interrupts
9-pin Cannon socket
9.6 Kbps to 12 Mbps, software-selectable
potential isolation:
- Data lines A, B
- Control lines RTS AS, RTS_PG
- 5 V supply voltage (max. 90 mA)
ground connection:
- DP12 connector cable shield
RS485, isolated *
5
automatically configured
