Alarm, error, and system messages

12.2 BIOS beep codes

SIMATIC IPC627C

104 Operating Instructions, 11/2010, A5E02669068-02

Display

(hex)

Meaning Description Remedy

51H DXE_SMART_TIMER_INIT 8259 Initial SMART Timer

initialization

Service case

52H DXE_PCRTC_INIT RTC Initial RTC initialization Service case

53H DXE_SATA_INIT SATA Controller

early initial

Advance initialization

of the SATA

Controller

Service case

54H DXE_SMM_CONTROLER_INIT Setup SMM

Control service,

DXE_SMMContr

oler_INIT

SSM Control service Service case

55H DXE_LEGACY_INTERRUPT Setup Legacy

Interrupt service,

DXE_LegacyInte

rrupt

Setup Legacy

Interrupt service

Service case

01H SEC_SYSTEM_POWER_ON CPU power on

and switch to

Protected mode

Switch to Protected

Mode

Service case

02H SEC_BEFORE_MICROCODE_PATCH Patching CPU

microcode

Load CPU Microcode Service case

03H SEC_AFTER_MICROCODE_PATCH Setup Cache as

RAM

Set up cache as RAM Service case

04H SEC_ACCESS_CSR PCIE MMIO

Base Address

initial

Initialize PCIE Service case

05H SEC_GENERIC_MSRINIT CPU Generic

MSR initial

Initialize CPU MS

(Machine Status)

Service case

06H SEC_CPU_SPEEDCFG Setup CPU

speed

Specify CPU speed Service case

07H SEC_SETUP_CAR_OK Cache as RAM

test

Carry out RAM Test

on cache

Replace basic

module

08H SEC_FORCE_MAX_RATIO Tune CPU

frequency ratio

to maximum

level

Setting CPU

frequency

Service case

09H SEC_GO_TO_SECSTARTUP Setup BIOS

ROM cache

Set up BIOS ROM

cache

Service case

0AH SEC_GO_TO_PEICORE Enter Boot

Firmware

Volume

Calling up the boot

firmware memory

area

Service case

70H PEI_SIO_INIT Super I/O initial Initialization of the

Super I/O

Service case

71H PEI_CPU_REG_INIT CPU Early Initial Initialize CPU

Service case

72H PEI_CPU_AP_INIT Multi-processor

Early initial

Multi processor

initialization

Service case

73H PEI_CPU_HT_RESET HyperTransport

initial

Initialize Hyper

Transport functionality

Service case
