Parameter assignment and operation of the device
8-
© Siemens AG 2010 All Rights Reserved
SICLOCK
®
TC100 Operating Instructions
Example 2:
Figure 8-6 Example 2 of one-button operation
The display shows the readout of the currently set IP gateway. A short button
press "turns the page" to readout the next parameter. A long button press is not
possible in this mask (no long arrow on the right).
Example 3:
Figure 8-7 Example 3 of one-button operation
The display shows the programming mode of a parameter, in this case an IP
address. A short button press can "turn the page" to another possible value
(
→ Select). A long button press can reset the parameter to the selected value
(
→ Reset).
Example 4:
Figure 8-8 Example 4 of one-button operation
At the end of the lists of pages, in most cases the operating level can be exited
by selecting "Exit" with a long button press, instead of having to wait for the auto-
matic exit after the timeout.
IP Gateway ->
000.000.000.000
-> Select -->Reset
192.168.001.010 ?
Next ->
Exit -->
