Parameter assignment and operation of the device
8-6
© Siemens AG 2010 All Rights Reserved
SICLOCK
®
TC100 Operating Instructions
Status display with queued message
Figure 8-4 Example of display during operation with error
The top line shows the message type and the date / time alternately. The mes-
sage text is shown scrolling through the bottom line.
When a message arrives, the background lighting is automatically switched on for
10 minutes.
Background lighting
Each time the button is pressed, the background lighting of the display is switched
on for 10 minutes.
EVENT
event-text event-text..
↔
19/09/2010 10:41:27
event-text event-text..
Table 8-2 Possible types of message
Display Description
INFO Current message is an info message
WARNING Current message is a warning
EVENT Other messages, e.g. an alarm
Note
Queued messages can be acknowledged by a long press on the MODE button.
If a current, unacknowledgable, persistent indication is pending, you can tempora-
rily change to the status display with a short press on the MODE button.
