Technical data
Type OSM-TX 150 S3 Rack
System unit CPU Pentium 4 processor 3.6 GHz
Second level cache 256 KB ECC
Memory 1 GB
Hard disk drives 1 x 73 GB, hot-plug
(max. 4 plug-in hard drives up to RAID level
5)
Diskette drive 3.5 inch, 1.44 MB
DAT drive (optional) DDS-4, 20 GB, 3 Mbyte/s, internal
DVD R/W drive (including CD R/W) 5.25 inch, 4x (DVD + only)
Graphics card on-board, 8 MB
Network card Intel 10/100/1000+ on-board with RJ-45
plug and 1 plug line 10BaseT, 3 m
Keyboard, mouse 2-button mouse
Watchdog group (optional) PCI group with 4 relay outputs
Interfaces
• 2 x RS-232-C (serial, 9-pin)
•
1 x Centronics (parallel, 25-pin,
EPP/ECP compatible)
• 3 x USB
•
2 x PS/2, mouse, keyboard
•
1 x VGA (15-pin)
Slots 5 x PCI, 1 x PCI Express (1x1)
Mounting slots
− for HD drives
−
for operable drives
4 x 3.5 inch for standard SCSI or hot-plug
SCSI (on insert) 2 x 5.25 inch free
Visualization (optional) Color monitor for workstation or B&W
monitor for system console
17 to 21 inch (TFT monitor recommended)
15"
Power Power supply 274 W (permanent supply)
Mains supply AC 100 to 240 V
Mains frequency 50 to 60 Hz
Dimensions / weight Dimensions (H x W x D) in mm 444 x 205 x 605 (without plug)
Weight ca. 28 kg, depending on configuration
Insertion height in rack 5 height units (U)
Ambient conditions Ambient temperature 10 to 35 °C, as per DIN EN 60721
Noise class 1 as per ISO 9296
Standards Product safety EN 60950 / IEC 60950
FCC guidelines Class A
Electromagnetic
compatibility
EN 55022 Class A
EN 55024
CE labeling as per EU directives 89/336/EEC (EMC)
73/23/EEC
