Features
The main control unit is based on a modern server PC.
The rack contains free PCI slots for fast I/O cards and an integrated graphics
processor.
The Pentium 4 processor has a speed of 3.6 GHz and 1 GB RAM.
A hot-plug capable 73 GB SCSI hard drive. Max. 4 hard drives can be inserted at RAID
level 5.
The first workstation, which also includes a system console, can be connected via the
built-in graphics processor (not included, but we recommend a TFT monitor); additional
workstations via the terminal bus.
The board comes with a network card with twisted pair plug (RJ45). A * m 10BaseT
cable is also included.
One DVD R/W drive (including CD R/W) is also included with the package.
Optional extensions
• PCI watchdog groups with 4 potential-free outputs.
• Data backup: DAT-Streamer (DDS-4) with a capacity of 20 GB.
• Interface multiplier to extend the number of serial interfaces (e.g. for message
printer).
• System bus adapter for industrial Ethernet.
• Serial radio clock module for DCF 77.
• Harddrive memory expansion as a mirrored drive up to RAID level 5.
• RAID controller for RAID level 5.
• E/P link to connect SIMATIC S7 via PROFIBUS.
• S5 link to add ISA components for exchanging servers.
• Uninterrupted power supply (UPS).
Software
SuSE Linux 8.2 serves as the operating system.
The Oracle workgroup server V9 is used to archive and administer data.
Both components are part of the SICLIMAT X basic package V 4.0 and are provided
with the same, but are not part of the package as described in this document.
Ordering
When ordering, please specify the quantity, product name, and type code.
Type Order number
Operator station
OSM-TX 150 S3 Rack
6FLOSMR-TXV4
