Data Sheet for Product

2/2
Siemens Building Technologies BS15C CK1N9826en
Landis & Staefa Division 09.03.2001
Ordering
When ordering, please specify the quantity, product name and type code.
Type Order No. Specification No.
BS15C 6FL4305-4HA14 15/42011A
Technical data
Type BS15C
Data Screen diagonal 35cm (viewable area)
Graphics resolution 1024 x 768 (max. 60Hz)
800 x 600 (max. 85Hz)
640 x 480 (max. 100Hz)
Dot pitch 0.28mm
Phosphor P22
Frequencies Horizontal 30 …54kHz
Vertical 50…120Hz
Average brightness > 100-130cd/m²
Preset image size Horizontal 260mm
Vertical 195mm
Protection class 1
Power supply Nominal voltage 110…240 V
Frequency 50…60 Hz
Power consumption Max. 100W
Stand-by mode < 10W
Off mode < 5W
Connections/interfaces Mains cable (1.5 m) Connected to PC output port
Data cable (1.5 m) SUB-D connector (15-pin)
Dimensions/weight Dimensions (H x W x D) 364 x 360 x 385mm
Weight 12 kg
Ambient conditions Ambient temperature (IEC 721) 15°C...32°C
Product safety Tested to EN 60.950
Radiated interference and interference
immunity
Meets the requirements for CE marking as
defined in EU Directive 89/336/EEC
(EN 55022/B, EN 50082-1);
Low radiation in accordance with MPR II
Ergonomic features GS mark
ISO 9241-3, -7, -8
ã 2001 Siemens Building Technologies Ltd. Subject to change
