Data Sheet for Product

3/4
Siemens Building Technologies XADPCC CK1N9866de
Building Automation 15.07.2002
Function workflow
The data gathered by the SICLIMAT X – PDS are adopted cyclically by the PC system,
and transferred to the PDM in the form of data series (recorded measured point with
interval) using DATASTUDIO. ADP or CC then reads the values from the PDM
database and evaluates them according to the respective functions.
Data transmission is secure and controlled by the application via FTP.
Engineering
The data to be transferred from the SICLIMAT X is engineered on the PC server by
using the PDS-PROJ engineering tool, which creates the PDS engineering file. Efficient
data transfer using powerful filter functions allows for easy engineering of the PDM data
basis.
Documentation
Commissioning guide for ADP / CC in connection with SICLIMAT X, contained
in the ZL PDS-PROJ package.
Ordering / scope of delivery
When ordering, please specify the quantity, product name, and type code.
Type Order no. Service specification no.
XADPCC package
comprising:
XADPCC configurator
ZL PDS 6FL 4214-4 NC47 12/26920
ZL PDS-PROJ-V2.0 6FL4214 -4ND14 12/26921
IBS documentation Comprised in ZL PDS-
PROJ package
-
PDM, DATASTUDIO, ADP, Version 2.2 See ADP packages
PDM, DATAPIPE, CC, Version 1.8
See CC packages
Prerequisites
Computer
• Windows 95, Windows 2000, Windows NT.
• Client, min. prerequisites:
− Pentium 3 processor or similar.
− 500 MHz, 256 MB RAM, 2 GB free hard drive space.
− SVGA screen (800 x 600) or higher.
Data storage
• External or internal MO drive or
• External or internal DAT streamer.
BACS connection
• Interface to the building automation and control system.
• Modem interface *
• Modem connected to PC (optional for remote maintenance).
* We recommend the use of a modem for system service and consulting.
Additional order
