Data Sheet for Product

CK1N9866en

15.07.2002

Siemens Building Technologies

Building Automation

SICLIMAT ™ X

SICLIMAT X with ADP and

/or CC

XADPCC

For long-term archiving and evaluation of data from SICLIMAT X on an external

PC featuring ADP (Advanced Data Processing) or CC (Consumption Control,

energy data evaluation).

Use

For long-term archiving and evaluation, SICLIMAT X transfers process data cyclically or

event-oriented manner to a PC-based system.

On the PC side, the data transferred via the SICLIMAT X PDS interface (process data

collector) is saved via the PDM (Process D

ata Manager) process to a database, and

evaluated using ADP (Advanced Data Processing) or CC (Consumption Control,

energy data evaluation).

The PC system is connected via Ethernet using TCP/IP to the SICLIMAT X.

PAGE 1
9 866 SICLIMAT ™ X SICLIMAT X with ADP and /or CC XADPCC For long-term archiving and evaluation of data from SICLIMAT X on an external PC featuring ADP (Advanced Data Processing) or CC (Consumption Control, energy data evaluation). Use For long-term archiving and evaluation, SICLIMAT X transfers process data cyclically or event-oriented manner to a PC-based system.
PAGE 2
Configuration The total configuration may feature different settings in dependence of the PDM/ADP/CC configuration. The illustration below shows a PDM server solution.
PAGE 3
Function workflow The data gathered by the SICLIMAT X – PDS are adopted cyclically by the PC system, and transferred to the PDM in the form of data series (recorded measured point with interval) using DATASTUDIO. ADP or CC then reads the values from the PDM database and evaluates them according to the respective functions. Data transmission is secure and controlled by the application via FTP.
PAGE 4
