User Manual

EPD - Type II
Based on ISO 14021
EPE EPE Bottom case
EPE EPE Cover
Notes on disposal
Total weight of device 791g
The total weight of a device may deviate from the total of the weights of all individual components due to rounding.
PC Film panel
Steel; chromeplate screw,nut: M4x8,M3x6,M3,M4
Steel; black oxidation screw M3x5
Cu alloy; inactivation M3x17.5 Cu stud 22.5
Al alloy; oxidation 40x60x5mm heat dissipation block
Al; oxidation 54mm DIN card rail
SECC+Steel; lacquered Bottom hosing
SECC+Steel; lacquered Cover housing
SECC; lacquered Small cover housing
PP+Cu CBL-USB-USB-AM/MICRO-USB-1m/RoHS 33g
silicone grease 20*20*2mm，15*25*2.5mm，11*15*5mm 9g
Terminal 25g
Others
Materials
Metals
Plastics
recyclable
Restricted Page 2/6
