EPD - Type II
Based on ISO 14021
Designation
Product line
Siemens Switzerland Ltd
Building Technologies Division
Gubelstrasse 22
CH-6301 Zug
Management System since by
ISO 9001 (Quality) 22.07.1986 SQS
ISO 14001 (Environment) 20.10.1998 SQS
OHSAS 18001 (OH&S) 01.01.2011 SQS
Typical energy consumption
variant *) see below
Symaro
Environmental
Product Declaration
QPM11xx and QPM21xxType of equipment /
Product No.
Duct Air Quality Sensor
Product
Process control
Product use
Typical energy consumption
variant *) see below
Maintenance
Fire protection according to
Fire load variant *) see below
20-PAP Corrugated fiber board Folded Box 51g
22-PAP paper incl. Label
4-LDPE Bag for accessories 4g
22-PAP paper Mounting instruction 4g
Notes on disposal
Total weight of device variant *) see below
The total weight of a device may deviate from the total of the weights of all individual components due to rounding.
PC; halogen-free Housing, socket and partition wall variant
PBT; halogen-free Immersion rod, complete variant
Epoxy resin; halogen-free Sealing compound variant
PA6; GF 0%; halogen-free Mounting flange / cable entry gland 25g
NBR; halogen-free O-ring gasket 1g
PET; halogen-free Washer 1g
Steel; zinc plated 5 screws 5g
Steel; zinc plated 4 screws variant
PBT / CuSn zinc-plated Connector measuring tip variant
PBT / CuSn zinc-plated Plug connector 2g
PA66 Cu steel Terminal strip with clip, screws variant
FR4; TBBA; solder SnAgCu PCB base 19g
FR4; TBBA; solder SnAgCu PCB gas module variant
FR4; TBBA; solder SnAgCu PCB cover module 14g
One-way, recyclable
Not necessary
EN 60730
Metals
Product use
Plastics
Risk of fire
Materials
Packaging
Others
PCBAs (Printed Circuit Board
assembled)
