Register name
Description
I/O
type
Modbus
function code
Modbus
register
type
Start
address
Register
number
Data type
value from QMX1.M34H
register
register
0x0001: occupied
0x0000: unoccupied
TempRoomEff
Room Temperature
effective for QMX1.M34H
visualization
AO
16: Write
multiple register
Holding
register
0
2
Float, F32-L-S
TempRoomSetpU
serOffsetEff
Setpoint shift effective for
QMX1.M34H
AO
16: Write
multiple register
Holding
register
2
2
Float, F32-L-S
TempRoomSetpA
bsEff
Present setpoint for
QMX1.M34H visualization
AO
16: Write
multiple register
Holding
register
4
2
Float, F32-L-S
PresenceStatusEf
f
Presence status for
QMX1.M34H visualization
AO
16: Write
multiple register
Holding
register
6
1
U16-B
0x0001: occupied
0x0000: unoccupied
PowerSupply
Power supply voltage for
QMX1.M34H
AO
16: Write
multiple register
Holding
register
8
1
U16-B
0x000F: 15 V power
supply (default value)
0x0018: 24 V power
supply
Conformity
Ambient conditions and protection classification
Degree of protection of housing to IEC EN 60529
IP30
Overvoltage category to IEC EN 60730-1
Class III
Climatic ambient conditions
● Transport (packaged for transport) as per
EN 60721-3-2
● Operation as per EN 60721-3-3.
● Class 2K3
Temperature -25...70 °C (-13... 158 °F)
Air humidity 5...95%.
● Class 3K5
Temperature -5...50 °C (23... 122 °F)
Air humidity 5...95%.
Mechanical ambient conditions
Transport as per EN 60721-3-2
Operation as per EN 60721-3-3
Class 2M2
Class 3M2
Standards, directives and approvals
EU conformity (CE)
A6V11791496*)
RCM conformity
A6V11791501*)
Environmental compatibility
The product environmental declaration (A6V11805936*) contains
data on environmentally compatible product design and assessments
(RoHS compliance, materials composition, packaging, environmental
benefit, disposal).
*) The documents can be downloaded from http://siemens.com/bt/download.
General data
General
Dimensions
86 mm × 86 mm × 16 mm
Color
Cover: White
Weight
Net weight: 87.9 g
Gross weight: 145.3 g
