Terminal layouts
PVM9
Control voltage DC 0 ...10 V
DC 0 ...10 V
SGND
AC 24 V, 50 ... 60 Hz
PVM9
Control voltage DC 0 ... 20 V phase cut
DC 0 ... 20 V phase cut
AC 24 V, 50 ... 60 Hz
Note:
Links 3 to 10 and 8 to 26
to be made at time of installation.
1
2
50280
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
Max. 32 W
Max. 32 W
twisted pairs
