Equipment combinations
The following cards can be inserted in the PRV… basic unit to form a BPS or NetBPS.
The type of card required depends on the planned application. The system overview in
this document as well as the respective cards' data sheets provide help for selection.
Card BPS NetBPS Type Data sheet
Program card Yes Yes PVA3... N8317
Communication card COM1 Yes No PVC1... N8311
Communication card COM1 No Yes BPS1.C1/1E N8313
Communication cards COM2 Yes Yes PVC2... N8312
The I/O module range can be connected to the basic units with P-bus in accordance
with the following data sheets:
Unit Type Data sheet
I/O modules with basic functions for
s
ignalling, measuring, counting, switching, or
positioning.
PTM1... N8111 .. N8171
The system overview in this data sheet shows the partner stations with which the BPS
can communicate via the Building Level Network (SDLC ring) or the NetBPS via
Ethernet. The number and composition of partners are project-specific.
Notes:
− The BPS can also exchange data with the listed stations via modem (telephony).
− Process stations on the Ethernet (NetBPS) can communicate only with a
superposed, operational VISONIK Data and Communication Server (DCS).
The following table shows the units required to integrate L&S room control systems in
the BPS/NetBPS:
System Bus Units Data sheet
MONOGYR MONOGYR bus Communication card PVC2.2M N8312
TEC/RWI FLN Communication card PVC2.1F N8312
BATIGYR BATIBUS Interface PNB
+ card COM1/V.24
N8942
N8311
DESIGO RX LON/LONMark Interface NIDES.RX
+ card COM1/V.24
N3299
N8311
The system overview in this data sheet shows the controllers that are able to
communicate with the BPS/NetBPS. The respective product range overviews and the
documentation on basics for system integration provide detailed information.
Third-party systems are integrated in the BPS/NetBPS via a COM1 communication
card on V.24 and a possible interface. Remember to clarify the hours required in terms
of software (for each project).
Cards
I/O modules
Partner stations
Integration of L&S room
control systems
Integration of third-party
systems
