User Manual

3/18
Siemens Building Technologies VISONIK Building Process Station BPS / NetBPS CM2N8305en
Landis & Staefa Division 05.10.2000
Type summary
Designation Type
Basic unit for P-bus and I/O modules, max. 32 LU *) PRV2.32
Basic unit for P-bus and I/O modules, max. 64 LU *) PRV2.64
Basic unit for P-bus and I/O modules, max. 128 LU *) PRV2.128
Basic unit without P-bus connection
As a master or CFE to integrate L&S room control systems and RWI
controllers as well as third-party system.
PRV2.00
*) LU = Load unit, 1 LU = 12.5 mA.
The PRV2.32, 64, and 128 have power supplies allowing for I/O modules up to a total load of 32 LU,
64 LU, or 128 LU.
Each basic unit accommodates a main circuit board and a power supply for the
respective type designation. Terminal block I is added. The unit is supplied for flush
panel mounting without base plate required for wall mounting/control cabinet
integration.
Order the required program and communication cards as well as the accessories
separately—delivery occurs separately.
A PVA3… program card is required for the BPS or NetBPS.
Designation Type
Communication Card COM1 for Building Level Network (SDLC) PVC1.1S
COM1 communication card for V.24 on TTY1 and TTY2. PVC1.1T
COM1 communication card for BLN + V.24 on TTY1 and TTY2. PVC1.1ST
COM1 communication card for Ethernet + V.24 on TTY1. BPS1.C1/1E
COM2 communication card for Floor Level Network (FLN). PVC2.1F
Communication cards COM2 for Monogyr bus (M-bus). PVC2.2M
Program card, small, with system software. PVA3.01/Vxx *)
Program card, big, with system software. PVA3.02/Vxx *)
*) The version designation /Vxx is a part of the ASN number and must be indicated on ordering; for
example PVA3.01/V14 (/Vxx corresponds to the current version).
Designation Type
Terminal block II for FLN and M-bus (10 items) PVX1.2PM
Terminal block III for SDLC and field telephone (4 items) PVX1.1C
Base plate for wall mounting (10 items) PRM1.1W
SDLC ring terminating resistor (10 items) PVR1.180
Address plug 1 ... 16 for I/O modules. PTG1.16
Address plug 1 ... 32 ditto PTG1.32
Address plug 33 ... 64 ditto PTG1.64
Address plug 65 ... 96 ditto PTG1.96
Address plug 97 ...112 ditto PTG1.112
Modem cable with D-sub plug 25-pin, int/ext, RXD/TXD straight. LVE1.2009
Tool cable for V24/V28 and BLN/FLN on ISDN plug. PRW1.7U28
Adapter with RJ45 plug on tool interface TTY3. PRW1.0U28
Adapter with D-sub plug 25-pin/int. on tool interface TTY3 PVW1.3F
Designation Type
POPcard operation (service cards VISONIK BPS) in German. PVP2.9D
POPcard operation (service cards VISONIK BPS) in English. PVP2.9E
Preprinted POPcards for project cards, paper (250 sheets) PUP1.1
Preprinted POPcards for project cards, plastic (100 sheets) PUP2.1
Card holder (100 items) PUP1.2
Basic units PRV2. ...
Ordering
Cards
Accessories
Operating cards
