Commissioning notes
Observe all country-specific safety regulations to prevent injuries and equipment
damages.
The battery is inserted in the unit upon delivery, but separated from the electrical circuit
with an isolating strip expanding at the upper compartment corner. After opening the
compartment, pull off the strip from the closed battery compartment.
The cover card for VISONIK inserted in the front has four symbols at the right margin
explaining basic information (unit type, software version, time, and date). This
information is displayed when the program card is inserted and the front door is closed.
The BPS/NetBPS can communicate with the I/O modules only if the address plug is
inserted and matches the addresses configured through software.
Prior to using the service cards, read the notes in document B8301E "Building Process
Station BPS User's Guide", Chapter "Important safety notes".
When the service card of the service set is inserted, you can check and conduct the
following via the displays and operating buttons:
• Test of the BPS/NetBPS (error messages, setting and resetting the clock).
• Query values and states at the inputs and outputs of the I/O modules.
• Change states and positioning values at the inputs and outputs of the I/O modules.
These service functions are available only if a program card is inserted. However, the
program card does not need to be configured for this purpose.
The BPS/NetBPS can locally be operated in two ways:
• Directly at the operating front via the plant-specific printed operating cards.
• By using the software programs "VISOTOOL Editor" or "New VISOTOOL Editor" via
the tool plug at the front of the unit.
Maintenance notes
The battery life is at least 4 years.
The battery status is monitored and insufficient load is indicated via the collective error
display (if the front cover is closed and if programmed).
Insufficient load does not impair the BPS/NetBPS functions provided sufficient
operating voltage is applied.
Battery
Front card
I/O module addresses
Service cards
Local operation
Battery life
STOP
