Technical data
7.6 Specific technical data
PM230 Power Module, IP55
Hardware Installation Manual, 12/2016, A5E35319202B AB
55
Table 7- 5 PM230, IP55, frame size C, 380 V AC … 480 V 3 AC
Article No. with filter, C2
Article No. with filter, C1
6SL3223-0DE31-1AG1
6SL3223-0DE31-1BG1
6SL3223-0DE31-5AG1
6SL3223-0DE31-5BG1
6SL3223-0DE31-8AG1
---
LO base load power
11 kW
15 kW
18.5 kW
LO base load input current
26.9 A
33.1 A
39.2 A
LO base load output current
26 A
32 A
38 A
HO base load power
7.5 kW
11 kW
15 kW
HO base load input current
18.6 A
26.9 A
33.1 A
HO base load output current
18 A
26 A
32 A
Fuse according to IEC
Fuse according to UL, class J
3NA3814
40 A
3NA3820
50 A
3NA3820
50 A
Power loss
0.32 kW
0.39 kW
0.46 kW
Required cooling air flow rate
20 l/s
20 l/s
20 l/s
Weight
9.5 kg
9.5 kg
9.5 kg
Table 7- 6 PM230, IP55, frame size D, 380 V … 480 V 3 AC
Article No. with filter, C2
Article No. with filter, C1
- 6SL3223-0DE31-8BG0
6SL3223-0DE32-2AG0
6SL3223-0DE32-2BG0
6SL3223-0DE33-0AG0
6SL3223-0DE33-0BG0
LO base load power
18.5 kW
22 kW
30 kW
LO base load input current
39.2 A
42 A
56 A
LO base load output current
38 A
45 A
60 A
HO base load power
15 kW
18.5 kW
22 kW
HO base load input current
33.1 A
36 A
42 A
HO base load output current
32 A
38 A
45 A
Fuse according to IEC
Fuse according to UL, class J
3NA3820
50 A
3NA3822
63 A
3NA3824
80 A
Power loss
0.46 kW
0.52 kW
0.68 kW
Required cooling air flow rate
20 l/s
39 l/s
39 l/s
Weight
30.2 kg
30.2 kg
30.2 kg
