Technical data
7.6 Specific technical data
PM230 Power Module, IP55
Hardware Installation Manual, 12/2016, A5E35319202B AB
53
7.6
Specific technical data
Note
Values for Low Overload and High Overload
The values for Low Overload (LO) are identical with those of t
he rated values.
Power loss of the Power Modules
The values specified for the power loss are typical values at 100% of the rated speed and
100% of the load corresponding to Low Overload.
Table 7- 2 PM230, IP55, frame size A, 380 V ... 480 V 3 AC
Article No. with filter, C2
Article No. with filter, C1
6SL3223-0DE13-7AG1
6SL3223-0DE13-7BG1
6SL3223-0DE15-5AG
6SL3223-0DE15-5BG1
6SL3223-0DE17-5AG1
6SL3223-0DE17-5BG1
LO base load power
0.37 kW
0.55 kW
0.75 kW
LO base load input current
1.3 A
1.8 A
2.3 A
LO base load output current
1.3 A
1.7 A
2.2 A
HO base load power
0.25 kW
0.37 kW
0.55 kW
HO base load input current
0.9 A
1.3 A
1.8 A
HO base load output current
0.9 A
1.3 A
1.7 A
Fuse according to IEC
Fuse according to UL, class J
3NA3803
10 A
3NA3803
10 A
3NA3803
10 A
Power loss
0.06 kW
0.06 kW
0.06 kW
Required cooling air flow
7 l/s
7 l/s
7 l/s
Weight
4.3 kg
4.3 kg
4.3 kg
Table 7- 3 PM230, IP55, frame size A, 380 V ... 480 V 3 AC
Article No. with filter, C2
Article No. with filter, C1
6SL3223-0DE21-1AG1
6SL3223-0DE21-1BG1
6SL3223-0DE21-5AG1
6SL3223-0DE21-5BG1
6SL3223-0DE22-2AG1
6SL3223-0DE22-2BG1
LO base load power
1.1 kW
1.5 kW
2.2 kW
LO base load input current
3.2 A
4.2 A
6.1 A
LO base load output current
3.1 A
4.1 A
5.9 A
HO base load power
0.75 kW
1.1 kW
1.5 kW
HO base load input current
2.3 A
3.2 A
4.2 A
HO base load output current
2.2 A
3.1 A
4.1 A
Fuse according to IEC
Fuse according to UL, class J
3NA3803
10 A
3NA3803
10 A
3NA3803
10 A
Power loss
0.07 kW
0.08 kW
0.1 kW
Required cooling air flow
7 l/s
7 l/s
7 l/s
Weight
4.3 kg
4.3 kg
4.3 kg
