Installing/mounting
4.1 Installation conditions
PM230 Power Module, IP55
20 Hardware Installation Manual, 12/2016, A5E35319202B AB
Inverters for plants and systems in the United States / Canada (UL/cUL)
● To ensure a design that is in conformance with UL/cUL, only use the approved fuses
specified in Section
Specific technical data (Page 53).
● Always use copper cables approved for 75 °C for Power Modules, frame sizes
FSD … FSF.
● The inverter provides internal motor overload protection in accordance with UL508C. The
protection threshold is 115% of the inverter full load current. When commissioning, you
can adapt the motor overload protection using parameter p0640.
● Suitable for overvoltage category III
Additional requirements for CSA compliance
Frame sizes FSA … FSC
● Rated voltage 480 V (phase to ground), 480 V (phase to phase)
● Suitable for SPD applications, type 1 or type 2
● Terminal voltage, VPR = 2,000 V
