Type summary
When ordering, please give product number, order number and description.
The mounting accessories not included in the scope of delivery must be ordered as
separate items.
1 x M16 cable gland for cable entry
2 x screw to DIN 7981-St 4.2 x 22 for direct mounting
1 x rubber grommet for capillary entries into air ducts
1) QAF63.6-J requires 2 AQM63.2
Product number Order number Description
QAF63.2-J S55700-P153 Frost unit with 2-m capillary
QAF63.6-J S55700-P154 Frost unit with 6-m capillary
Ordering
Accessories
Included in the scope
of delivery
Not included in the
scope of delivery
Product
number
Order
number
Designation Parts
AQM63.0 BPZ:AQM63.0 Mounting flange 1 x depth-adjustable mounting
flange for the housing
AQM63.2
1)
BPZ:AQM63.2
Capillary support 3 x capillary tube clamp
3 x spacer
