• Connect all ECGs and luminaires
• Supply all lights with mains voltage (230V).
Only then you should supply the gateway with
main voltage, because the external voltage test
is only carried out when the gateway starts
• Apply 17–19 V DC DALI voltage at each ECG
and at the terminals D+/D- of the gateway
• Switch gateway to direct operation by
pressing (> 3 s) ➜ Display shows _d
• Use the up and down arrows (▲ and ▼) to switch
the lights on and off or make them brighter or darker
• Check whether all lights are working
Installation checklist for KNX/DALI Gateways
Hold down to switch
gateway to direct operation
(Display shows _d)
