Pendant luminaire with sensor
2
DALI sensor
3
Ceiling luminaire with sensor
KNX offers complete integration of
the DALI lighting system into a building
automation system via a DALI or KNX
interface. Using brightness sensors with
an integrated DALI interface is particularly
efficient for pendant luminaires, as the
sensor in the luminaire only needs to
be connected to DALI. The KNX/DALI
Gateways plus also include a built-in
constant light control system, with
which a main lighting group and up
to four secondary lighting groups can
be controlled for demand-driven and
energy-efficient lighting in rooms.
Integrated constant lighting control with DALI sensors
4
KNX presence detector
5
KNX push button
6
KNX/DALI Gateway Twin plus
1
/
3
DALI-sensor mounted in
a pendant luminaire
➜ only DALI-cable
(no additional KNX bus cable
required in the luminaire).
1
2
3 4
5 6
DALI
AC 230 V
KNX
30% 40% 70%
